VENTILATION

Vyaire™
UltraBlender Low Flow

Product Description

The UltraBlender low flow has the same specifications has the MicroBlender low flow, but includes two pressure compensated flowmeters mounted to either side. Available in a variety of different configurations, the UltraBlender is a good option for NICUs and PICUs.

  • These air/oxygen blenders feature two pressure compensated flowmeters mounted to either side of the unit.
  • An alarm activation and bypass feature is triggered when the supply gas pressures differ by 20 ± 2 psi. T

#

Part No.

Description

1

00060

Hose, oxygen, high pressure, 15’, male/female

2

03868

Hose, oxygen, high pressure, 3’, male/female

3

02899

Hose, air, high pressure, 15’, female both ends

4

03867

Hose, air, high pressure, 3’, female both ends

5

04322

Bracket, pole mount

6

05141

Bracket, wall mount

7

05213

Bracket, wall mount, female

8

03017

Bracket, pole mount BHH

9

09440

Bracket, rail mount

10

09437

Bracket, rail mount

11

2688-332

Adapter, 90’ elbow

12

05473

Adapter, DISS air/oxygen

13

07426

Air inlet filter/water trap

#

Part No.

Description

1

10040A (DISS)

(left-side flow meter) 2.0–16 LPM, increments of 1, (right-side flow meter) 0.1–1.0 LPM, increments of 0.1

2

10041A (DISS)

(left-side flow meter) 2.0–16 LPM, increments of 1, (right-side flow meter) 0.5–5.0 LPM, increments of 0.5

3

10042A (DISS)

(left-side flow meter) 2.0–16 LPM, increments of 1, (right-side flow meter) 1.0–10 LPM, increments of 1

4

10046A (DISS)

(left-side flow meter) 2.0–16 LPM, increments of 1, (right-side flow meter) 1.0–10 LPM, increments of 1

5

10047A (DISS)

(left-side flow meter) 1.0–10 LPM, increments of 1, (right-side flow meter) 0.1–1.0 LPM, increments of 1

6

10048A (DISS)

(left-side flow meter) 0.5-5.0 LPM, increments of 1, (right-side flow meter) 1.0–10 LPM, increments of 1

7

10049A (DISS)

(left-side flow meter) 1.0–10 LPM, increments of 1, (right-side flow meter) 1.0–10 LPM, increments of 1
